114 MINI

Portable threading machine

114 MINI Portable threading machine Portable threading machine mod. 114 MINI are designed to wear well, thank to its exclusive driving system without worn screws. Machine could thread from 1/4 up to 1”1/4. Using adapter mod. 97 is possible to thread from 2”1/2 up to 4”

TECHNICAL FEATURES:
- CEI double isulated motor 230V/900W/50-60 HZ (110 V on request)
- Aluminium body
- Die-casted steel gears
- Mechanical driving and inverter

PERFORMANCE :

- Right threading up 1”1/4
- Threading speed: 30 RPM
- Reverse speed: 80 RPM
- Weight: 4,6 kg. (machine only)

OPTIONALS:

- Threading heads 1/4 and 3/8
- NPT threading heads
